7 inches touch screen with resolution of 1024 x 600.
Support 10 channel camera for backup and recharge.
Priority exporting channel supported.
Support Ethernet port for network function.
Local search and playback supported.
Fast data export and battery recharge.
Support to upload data to the center server automatically.
Support different user authority access.
Screen
7” Touch Screen, Resolution 1024 x 600
Memory
4GB
Operating System
Windows10 (64bit)
Local Storage
Support 2 disks (each one can up to 8TB)
Data Interface
10 channel optional (USB connection)
Automatically Backup
When BWC connect to the terminal, it will back up all the video, audio, pictures and log file automatically
Priority Backup
The terminal has one priority backup channel; it will back up the data from this interface firstly
Storage Empty
The terminal will empty all the data in the BWC when the backup finished.
User Pairing
When the BWC paired with one user, the terminal can read the data from this BWC automatically.
Status Display
During the backup progress, it can display the device id, name, group, storage space, backup status and so on
Upload
All the marked video files will upload to the center server automatically based on the grade and network status.
Data Overwrite
The system will overwrite all the unmarked video and old data automatically based on a certain time.
Playback
The authorized people can login the software to playback any video he have searched, and it support playback full screen, forward and back, pause and so on.
System Log
System will record all operation log of the terminal
Data Search
The authorized people can login the software to search any files based on recording date/ time, uploaded date/time, unit number, officer number, officer name, group name, file type, data level, remark info and so on.
Backup
The terminal can back up all the data automatically, also, center server can remote backup all the file manually
Backup Time
10 channel 16G data can be finished in 90 minutes, and 10 channel 16GB data can be finished in 110 minutes.
Auto-archiving
When all the data finished backup, the terminal will archive and classify all the data based on recording date/time, device number, username, group name, video type, and video size and so on.
Recharging
10 channels BWC can finish recharging in 4 hours and 45 minutes if the unit is OFF, if it’s ON, it need about 6 hours. 10 channels BWC can finish recharging in 5 hours if the unit is OFF, if it’s ON, it need about 6 hours and 15 minutes
Security
Only authorized people can access the terminal to backup data
