WPA/WPA2 security mechanism (WPA-PSK uses TKIP or AES)
Network standard
EC20 CE FHKG
LTE-FDD (Support Hierarchical Reception)
B1/B3/B5/B8
LTE-TDD (Supports Hierarchical Reception)
B38/B39/B40/B41
WCDMA
B1/B8
GSM
900MHz/1800MHz
CDMA
BC0
TD-SCDMA
B34/B39
LTE Features
Maximum support for 3GPP R8 non-CA Cat 4 FDD and TDD Support 1.4MHz~20MHz RF bandwidth Downlink support MIMO LTE-FDD: The maximum downlink rate is 150Mbps,and the maximum uplink rate is 50Mbps LTE-TDD: Maximum downlink rate is 130Mbps,maximum uplink rate is 35Mbps
UMTS Features
Support 3GPP R8 DC-HSDPA, HSPA+, HSDPA, HSUPA and WCDMA Support QPSK, 16-QAM and 64-QAM modulation DC-HSDPA: Maximum downlink rate 42Mbps HSUPA: Maximum uplink rate 5.76Mbps WCDMA: The maximum downlink rate is 384Kbps, the maximum uplink rate is 384Kbps
CDMA Features
Support 3GPP2 CDMA2000 1X Advanced and 1xEV-DO Rev.A EVDO: The maximum downlink rate is 3.1Mbps, the maximum uplink rate is 1.8Mbps 1 x Advanced: Maximum downlink rate 307.2kbps, maximum uplink rate 307.2Kbps
TD-SCDMA Features
Support CCSA Release 3 TD-SCDMA Maximum downlink rate 4.2Mbps, maximum uplink rate 2.2Mbps
Operating Mode
4G access, Routing mode, AP mode
Wireless Configuration
Wi-Fi basic parameter configuration/blacklist
Network Settings
Operating mode LAN port/WAN address setting.
Power
Connected to the power source, the POWER light is always on in blue
4G
In 4G network mode, and when the 4G network is normal, the 4G light is always on in blue; in 4G mode, the 4G is abnormal, and the blue indicator light flashes
WAN
When there is data access, the WAN indicator light is always blue
