| Image Sensor | 1/2.8" 2Megapixel Progressive scan CMOS (0.9071cm) |
|---|---|
| Minimum Illumination | 0.002 Lux@F1.7 |
| Effective Pixels | 1920 (H) × 1080 (V) |
| Shutter Speed | Auto/Manual, 1/3~1/100000s |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual |
| Lens | C/CS |
| Gain Control (AGC) | Auto/Manual |
| Video Compression | Instastream/H.265/H.264+/H.264/H.264B/ H.264H/ MJPEG (sub stream) |
| Back Light Compensation | BLC/HLC/WDR(120dB) |
| Video Streaming | Main Stream: 1080P (1 fps–25/30fps), Sub Stream: D1 (1 fps–25/30fps), Third Stream: 1080P (1 fps–6fps), Quad Stream: D1 (1 fps–6fps) |
| Privacy Mask | Off/On (4 Area, Rectangle) |
| ICR | Auto (ICR)/Color/B/W |
| Resolution | 1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
| ROI | Off/On (4 Zone) |
| Audio Input | 1 Ch. |
| Motion Detection | Off/On (4 Zone, Rectangle) |
| Audio Output | 1 Ch. |
| Audio Compression | G.711a; G.711Mu; G726; AAC; G.723 |
| Alarm IN | 2 channel In: 5mA 5V DC |
| Alarm Out | 1 channel Out: 1A 30V DC/0.5A 50V AC |
| Smart Detection | Tripwire; intrusion;Object Abandoned/Missing, Heat Map; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection |
| Protocol | IPv4;IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP, ONVIF (Profile S/ Profile G/T/Q), InstaOn, CGI, Milestone |
| Ethernet | RJ-45 (10/100Base-T) |
| People Counting | Support the counting of enter number, leave number, and pass number, and displaying and outputting yearly/monthly/daily reports. |
| Smart Phone | iPhone, iPad, Android Phone |
| Face Detection | Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo; three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting |
| Micro SD | NAS; FTP; SFTP, Micro SD card 256GB |
| Operating Temperature | -30°C to +60°C (-22°F to +140°F)/Less than 95% RH |
| Power Source | DC 12V (±25%), AC 24V (±25%), PoE (802.3af), ePoE |
| Power Consumption | <9.5W |
| Casing | Metal |
| Dimension | 135.4 mm × 74.4 mm × 65.5 mm |
| Weight | 0.53 kg |
