| Image Sensor | 1/2.9 |
|---|---|
| Minimum Illumination | 0.005 lux@F1.5 (Color, 30 IRE) 0.0005 lux@F1.5 (B/W, 30 IRE) 0 lux (Illuminator on) |
| Effective Pixels | 2688 (H) × 1520 (V) |
| Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| RAM & ROM | 512 MB & 128 MB |
| Iris Control | Fixed |
| DORI Distance | W: 64.0m (Detect), 25.6m (Observe), 12.8m (Recognize), 6.4m (Identify), T: 210.0m (Detect), 84.0m (Observe), 42.0m (Recognize), 21.0m (Identify) |
| Gain Control (AGC) | Auto |
| Lens | 2.7 mm–13.5 mm |
| Lens Mount | φ14 |
| Lens Type | Motorized Lens |
| Max Aperture | F1.5 |
| Close Focus Distance | 0.8 m (2.62 ft) |
| Pan, Tilt, Rotation | Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| S/N Ratio | >56 dB |
| Video Compression | H.265; H.264; Smart H.264+, H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Encode Strategy | Instastream, AI Instastream |
| stream Capability | 3 streams |
| Angle of View | H: 104°–29° V: 54° –16° D: 125° –33° |
| Smart search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Back Light Compensation | BLC / HLC / WDR(120dB) |
| Video Streaming | Main stream: 2688 × 1520 @ (1–25/30) fps Sub stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @(1–30 fps) Sub stream 2: 1920 × 1080 @ (1–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity |
| Resolution | 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M(1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480) |
| Noise Reduction | 3D NR |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Privacy Mask | 4 areas |
| ROI | Support (4 areas) |
| Audio | Built-in Mic |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm IN | 1 channel in: wet contact, 5 mA 3 V–5 VDC |
| Alarm Out | 1 channel out: wet contact, 300 mA 12 VDC |
| Bit Rate | H.264: 3 kbps–8192 kbps H.265: 3 kbps–8192 kbps |
| Bit Rate Control | CBR/VBR |
| Protocol | IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; InstaOn, ONVIF (Profile S/Profile G/Profile T); CGI, Milestone; Genetec |
| Day/Night | Auto (ICR)/Color/B/W |
| SDK and API | Support |
| Ethernet | RJ-45 (10/100 Base-T) |
| Alarm Event | No SD card; SD card full; SD card error; service life warning (only supported by CP Plus card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception |
| Cyber Security | Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade |
| Image Rotation | 0°/90°/180°/270° (support 90°/270° with 2688 × 1520 resolution and lower) |
| AI SSA | Support |
| Mirror Function | Support |
| Defog | Support |
| Scene Self-adaptation (SSA) | Support |
| User Account | 20 (Total bandwidth: 64 M) |
| Browser | IE: IE11, Chrome, Firefox |
| Smart Phone | iPhone, iPad, Android Phone |
| IR Control | Auto/Manual |
| No of IR LEDs | 4 (IR LED) |
| IR Distance | IR Range of 60Mtr. |
| Storage | FTP; SFTP; Micro SD card (support max. 512G); NAS |
| Intelli Check | With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events |
| IVS | Tripwire, intrusion (support the classification and accurate detection of vehicle and human) |
| Power Source | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 2.8 W (12 VDC); 3.6 W (PoE), Max. (WDR + IR intensity + Intelligence): 7.9 W (12 VDC); 9.2 W (PoE) |
| Storage Temperature | –40 °C to +60 °C (–40 °F to 140 °F) |
| Operating Temperature | –30 °C to +60 °C (–22 °F to 140 °F) |
| Humidity | Less than 95% RH |
| Weatherproof Standard | IP67 |
| Casing | Metal |
| Dimension | 244.1 mm × 79.0 mm × 75.9 mm |
| Weight | 820 g (1.81 lb) |
