Main stream: 2880 × 1620@(1–20)fps/ 2960 × 1668@(1–20)fps/ 2688 × 1520@(1–25/30fps) Sub stream 1: 704 × 576@(1–25fps)/ 704 × 480@(1–30fps) Sub stream 2: 1920 × 1080@(1–25/30fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
SDK and API
Support
Scene Self-adaptation (SSA)
Support
Smart Detection
Tripwire, intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
AI SSA
Support
AFSA
Support
Intelli Check
With AI NVR, intelli check up the human/vehicle targets that users are interested in from SMD events
OTA (Online Device Upgrade)
Support
Cloud Health Monitoring System (HMS)
Support
Defog
Support
Alarm Event
No SD card; SD card full; SD card error; service life warning (only supported by CP Plus card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception
Ethernet
RJ-45 (10/100Base-T)
User/Host
20 (Total bandwidth: 64Mbps)
Smart Phone
iPhone, iPad, Android Phone
IR Distance
IR Range of 50 Mtr., Smart IR
No of IR LEDs
1
Browser
IE: IE11, Chrome, Firefox
Micro SD
Micro SD card (support max. 512GB)
Storage
FTP; SFTP, NAS
Operating Temperature
-40°C to +60°C (–40°F to 140°F)
Storage Temperature
-40°C to +60°C (-40°F to 140°F)
Operating Humidity
Less than 95% RH
Power Source
12 VDC/PoE (802.3af)
Power Consumption
Basic: 3.1 W (12 VDC); 3.7 W (PoE) Max. (WDR+IR intensity+ Intelligence on): 5.3 W (12 VDC); 6.5 W (PoE)
