Main stream: 2880 × 1620@(1–20)fps/ 2960 × 1668 @(1–20)fps/ 2688 × 1520@(1–25/30fps) Sub stream 1: 704 × 576 @ (1–25fps)/ 704 × 480 @(1–30fps) Sub stream 2: 1920 × 1080@(1–25/30fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
Tripwire, intrusion (support the classification and accurate detection of vehicle and human)
Ethernet
RJ-45 (10/100Base-T)
Event Trigger
No SD card; SD card full; SD card error; service life warning (only supported by CP Plus card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; Security Exception
User Account
20 (Total bandwidth: 64 M)
Smart Phone
iPhone, iPad, Android Phone
IR
IR Range of 60 Mtr., Smart IR
Micro SD
FTP; SFTP; Micro SD card (support max. 512GB); NAS
Operating Temperature
-30°C to +60°C (-22°F to +140°F)
Power Source
12V DC/PoE
Power Consumption
Basic: 2.8 W (12 VDC); 3.4 W (PoE) Max. (WDR + IR intensity + Intelligence): 7.4W (12 VDC); 8.5 W (PoE)
