Image Sensor | 1/1.8” 4MP PS CMOS Image Sensor (1.411 cm) |
---|---|
Minimum Illumination | 0.001 [email protected] |
Effective Pixels | 2688(H) x 1520(V) |
Shutter Speed | Auto/Manual, 1/3~1/100000s |
White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
Iris | Auto Aperture |
Lens | 2.7~12 mm motorized Lens |
Max Aperture | F1.2 |
Close Focus Distance | W: 1m ; T: 2.5m |
Gain Control (AGC) | Auto/Manual |
Encode Strategy | Instastream |
Video Compression | H.265, H.264+, H.264, H.264H, H.264B, MJPEG |
Angle of View | Horizontal: 114°(W)–47°(T) Vertical: 59°(W)–27°(T) Diagonal: 141° (W–55°(T) |
Back Light Compensation | BLC/ HLC/ WDR(140dB) |
Video Streaming | Main Stream: 2688 × 1520 (1–50/60 fps) sub stream 1: 704 × 576 (1–25/30 fps) sub stream 2: 1920 × 1080 (1–25/30 fps) sub stream 3: 1920 × 1080 (1–25/30 fps) sub stream 4: 704 × 576 (1–25/30 fps) |
Privacy Mask | 4 areas |
DORI Distance | W- 60.1m (Detect) 24m (Observe) 12m (Recognize) 6m (Identify) T- 128.6m(Detect) 51.4m (Observe) 25.7m (Recognize) 12.8m (Identify) |
ICR | ICR switch |
Resolution | 4M (2688 × 1520), 3M (2304 × 1296), 1080p (1920 × 1080), 1.3M (1280 × 960), 720p (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
ROI | Yes (4 areas) |
Audio Input | 1 Ch. |
Motion Detection | OFF/ON (4 areas, rectangular) |
Audio Output | 1 Ch. |
Audio Compression | G.711a; G.711Mu; G726; AAC; G.723 |
Alarm IN | 3 channel In: 5mA 5V DC |
Alarm Out | 2 channel Out: 1000mA 30V DC/500mA 50V AC |
Bit Rate | H.264: 32–10240 kbps H.265: 12–10240 kbps |
Smart Detection | Abandoned object, moving object |
Protocol | HTTP; HTTPS; 8021.x; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP; QoS; UPnP; NTP; SFTP; RTMP; Genetec; Bonjour; ONVIF (Profile S/Profile G/ Profile T); CGI; InstaOn |
Perimeter Protection | Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering |
Video Metadata | Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction. |
Ethernet | RJ-45 (10/100/1000 Base-T) |
People Counting | People counting (count the entry number, exit number and pass number), display and output daily/monthly/annual statistics, No. in area |
Smart Phone | iPhone, iPad, Android Phone |
Intelligent Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
IR | IR Range of 60 Mtr. |
Face Recognition | Face recognition, track, priority, snapshot, face enhancement, face exposure, face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mask, beard. Face matting setting: face, single inch photo. Two snapshot strategies: priority snapshot, recognition. Face angle filter Priority time setting Management of 5 group face libraries Single person register and person register in batch Face recognition and similarity setting |
Micro SD | FTP; Micro SD card (256 GB); NAS; SFTP |
Operating Temperature | -40°C to +60°C (-40°F to +140°F), ≤95% |
Power Source | 12V DC/24V AC/PoE |
Power Consumption | <17.3W |
Weatherproof Standard | IP67 & IK10 |
Casing | Metal + Plastic |
Dimension | 340.1 mm × 108.5 mm × 92.9 mm (L × W × H) |
Weight | 1600g |
