Main stream: 1920 × 1080@(1–25/30)fps; Sub stream 1: 704 × 576@(1–25fps)/ 704 × 480@(1–30 fps) Sub stream 2: 1920 × 1080@(1–25/30fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
Tripwire, intrusion (support the classification and accurate detection of vehicle and human)
Ethernet
RJ-45 (10/100Base-T)
Alarm Event
No SD card; SD card full; SD card error; service life warning (only supported by CP Plus card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception
SMD PLUS
SMD 4.0
User Account
20 (Total bandwidth: 64 M)
SDK and API
Yes
Smart Phone
iPhone, iPad, Android Phone
IR Range
IR Range of 40 Mtr., Smart IR
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Micro SD
FTP; SFTP; Micro SD card (support max. 256 G); NAS
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Operating Temperature
-30 °C to +60 °C (–22 °F to 140 °F)
Storage Temperature
-40°C to +60°C (-40°F to +140°F)
Power Source
12 VDC/PoE (802.3af)
Power Consumption
Basic: 2.3 W (12 VDC); 2.9 W (PoE) Max. (WDR + IR intensity + Intelligence): 6.6 W (12 VDC); 7.7 W (PoE)
