Main stream: 3840 × 2160@(1–20fps by default) 3840 × 2160@(1–25/30fps when AI function disabled) sub stream: 704 × 576 @(1–25fps)/704 × 480@(1–30fps) third stream: 1920 × 1080@(1–25/30fps)
No SD card; SD card full; SD card error; service life warning (only supported by CP Plus card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; voltage detection; SMD; Security exception
SDK and API
Yes
Perimeter Protection
Tripwire; intrusion (support the classification and accurate detection of vehicle and human).
Cyber Security
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Weatherproof Standard
IP67, IK10
Operating Temperature
-40°C to +55°C (–40°F to +131°F)/Less than 95% RH
Storage Temperature
-40° C to +60° C (-40° F to +140° F)
Micro SD
FTP; Micro SD card (256GB); NAS; SFTP
Casing
Metal
Power Source
12V DC/PoE (802.3af)
Power Consumption
Basic power consumption: 2.7W (12V DC); 3.6W (PoE) Max. power consumption (WDR + H.265 + IR LED intensity): 6W (12V DC); 7W (PoE)
