Auto; natural; street lamp; outdoor; manual; regional custom
DORI Distance
3.6mm- 85.4 m (Detect) 34.2 m (Observe) 17.1 m (Recognize) 8.5 m (Identify), 2.1mm– 52.0 m (Detect) 20.8 m (Observe) 10.4 m (Recognize) 5.2 m (Identify), 2.8mm- 63.6 m (Detect) 25.4 m (Observe) 12.7 m (Recognize) 6.4 m (Identify), 6mm- 124.0 m (Detect) 49.6 m (Observe) 24.8 m (Recognize) 12.4 m (Identify)
Close Focus Distance
2.1mm: 0.5 m; 2.8mm: 0.9 m; 3.6mm: 1.6 m ; 6mm: 3.2 m
Mount Type
M12
Lens
3.6mm (2.1mm, 2.8mm, 6mm optional)
Iris Control
Fixed
Max. Aperture
2.1 mm: F2.0; 2.8 mm; 3.6 mm; 6 mm: F1.4
Lens Type
Fixed focal
Gain Control (AGC)
Auto
Video Compression
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Main stream: 2688 × 1520 @ (1–25/30) fps, Sub stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) Sub stream 2: 1920 × 1080 @ (1–25/30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity
Tripwire, intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
AI SSA
Support
Quick Pick
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events
SDK and API
Support
Cyber Security
Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Alarm Event
No SD card; SD card full; SD card error; service life warning (only supported by CP Plus card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception
Ethernet
RJ-45 (10/100Base-T)
User Account
20 (Total bandwidth: 64 MB)
Smart Phone
iPhone, iPad, Android Phone
IR Range
IR Range of 30 Mtr., Smart IR
No of IR LEDs
2 (IR LED)
Micro SD Card
Micro SD card 256GB
Storage
FTP; SFTP; NAS
Scene Self-adaptation (SSA)
Support
Browser
IE: IE11 Chrome Firefox
Operating Temperature
-40 °C to +60 °C (–40 °F to 140 °F) /Less than 95% RH
Storage Temperature
-40 °C to +60 °C (–40 °F to 140 °F)
Power Source
12 VDC/PoE (802.3af)
Power Consumption
Basic: 3.8 W (12 VDC); 4.6 W (PoE), Max. (WDR + IR intensity + Intelligence): 5.9 W (12 VDC); 7.2 W (PoE)
