Auto record; manual record; search video detection; IO alarm; thermal imaging; intelligent event; all record file
Backup Mode
HDD, peripheral USB storage device
IP SAN Performance
280-channel × 2 Mbps video stream writing and 24-channel × 2 Mbps video playback (I/O size of VMS is 64 KB) 400-channel × 2 Mbps video stream writing and 24-channel × 2 Mbps video playback (I/O size of VMS is 512 KB)
Video Compression
H.265; Smart H.264+; H.264; MJPEG
Thermal Camera Compatibility
Works with camera for fire alarm, temperature alarm, temperature difference alarm, hot spot, cold spot, smoking and calling
Face detection, face recognition, IVS (abandoned object, missing object, loitering, crowd gathering, parking, fence-crossing, fast moving, tripwire and intrusion), video metadata (human, vehicle, non-motor vehicle), vehicle recognition, people counting (fisheye or people counting camera required), face & body detection, crowd distribution, smart thermal (call detection, visible channel- smoking detection, thermal channel-smoking detection)
IPC offline alarm; storage error; HDD full; video frame loss; SSD exception; IP conflict; MAC conflict; login lock; fan malfunction; no HDD; network security exception; power exception; disk health exception; RAID exception; storage pool exception; temperature alarm; share service
Audio Compression
G.711A; G.711U; PCM; G726
Alarm Linkage
Record; snapshot (full image); alarm uploading; remote device alarm output; camera audio; buzzer; log; preset; email, smart tracking and warning light. Disarming alarm linkage action by period or one-click sync disarm config with channels
Storage Method
Internal HDD and network disk
Hard Disk
16 slots, SATA Max.18TB/HDD hot swapping CMR support enterprise-grade HDD
iSCSI
Supports client and Server
Interface Ports
1 eSATA Port, 1 RS232 port, for debug or COM data transmission, 2 ports. 2 USB 3.0 Ports at the rear panel, 1 HDMI Port, only for debug, 1 VGA Port, only for debug
Network Disk
Supports client
Record Management
Supports record control (continuous, event-based, scheduled, scheduled & event-based)
